Product Description
Automatic brazing change and strong off-road performance shorten rig auxiliary time. The large-displacement high-pressure screw air compressor enables thorough slag discharge, which is more conducive to a substantial increase in rock drilling speed and reduces the consumption of drilling rigs. The powerful propulsion and rotary design solves the problem of drill sticking in complex rock formations on the basis of satisfying high-speed rock drilling. One-person operation reduces labor costs.
Environmental friendly
The standard two-stage dry dust collection device and the optional wet dust collection device not only meet the environmental protection needs of mines and operators, but also greatly reduce the pollution of dust to the equipment itself.
Energy saving
A single engine drives the screw air compressor and hydraulic system at the same time. Compared with the split drilling rig diesel engine, the total power is reduced by about 35%, and the maintenance cost is reduced by 50%.
The crawler leveling device makes the center of gravity of the drilling rig more stable when going up and down slopes. The strong operating capacity reduces the number of equipment and personnel required in the mine. The protection design of the brazing bin and cab eliminates hidden dangers for personnel.
Specification
| Main technical specifications | ZGYX-453 |
| engine | YC6L260-H300 |
| 230kw@2,150rpm | |
| Aperture range | φ90-138mm |
| Storage quantity | 7+1 |
| Drill pipe specification | φ76x3,000mm |
| Impactor | 4" |
| working torque | 2,800N.m |
| Exhaust air volume F.A.D | 16m3/min |
| work pressure | 17bar |
| Pulling force | 31kN |
| Walking speed | 3km/h |
| 2km/h | |
| Gradeability | 30º |
| track frame swing | ±10º |
| Total Weight | 15,000Kg |
| Shipping Dimensions (LxWxH) | 9,000 x 2,300 x 3,000mm |
